Name: Blacking Internal Ring Gear OEM High Strength And High Precision Long Using Life
Brand: Zhuzhou Gears Auto Parts Co., Ltd.
Availability: InStock

Home Products Internal Ring Gear

Blacking Internal Ring Gear OEM High Strength And High Precision Long Using Life

Product Details:

Place of Origin:	ZhuZhou,HuNan,China(mainland)
Brand Name:	JICHI
Certification:	DIN, ISO/GB, AGMA, JIS

Contact Now

Detailed Product Description

Tooth Profile:	Spur	Processing:	Shaping
Model Number:	Internal Ring Gear	Material:	Steel,20CrMnTi
Pressure Angle:	20 Degree	Size:	Standard Size
Highlight:	internal tooth gear , internal helical gear

Blacking Internal Ring Gear OEM High Strength And High Precision Long Using Life

Product Description

These internal spurs have a cylindrical pitch surface and teeth which are parallel to the axis. However, the internal spur gear teeth are formed on the inner surface of a cylinder. Also, the precision engineered mating component will be an external spur gear. The teeth are machined during the shaping production step.

When manufacturing ring gears, increased durability is the most important factor to focus on achieving. Ring gears manufactured by Longsum allow for very close proximity operation versus externally toothed gears. Also, ring gears include customizable pressure angles to mate with nearly any accompanying gear. Our custom ring gear products are most ideal for light applications, through smooth, quiet operation. These products are manufactured to transmit power control between parallel shafts, that operate in a similar plane.

Our Services

Gear Types	spur gear, helical gear, internal spur gear, ring gear, straight/spiral bevel gear, hypoid gear, crown wheel & pinion, gear shaft, worm gear & worm shaft, spline shaft & bushing, etc.
Gear Material	carbon steel, alloy steel, stainless steel, brass, bronze, casting iron, nylon, etc. { GB Steel: C45, 40Cr, 20CrMo, 20CrMoTi, 17CrNiMo6, 20CrMnTi, 42CrMo, etc. }
Processing	gear blank turning, gear hobbing, gear milling, gear shaping, gear shaving, tooth grinding, broaching, etc.
Heat Treating	quenching, carburizing, nitriding, carbon-nitriding, salt bath quenching, etc.
Application	Automotive, Agricultural, Electronic, Industrial, Medical, Defense, Off-highway, ect.
